LTC212 12 Tons Double Drum Vibratory Road Roller With Famous Engine
Main Features
1.Full hydraulic two wheel drive and vibration;
2.Double frequency double vibration system;
3.Hydrostatic center articulated steering, patented crab mechanism;
4.Cab with air conditioner ,comfortable and spacious ,the flexible steering seat;
5.The driver’s cabin can be turned on one side as a whole, to facilitate maintenance;
6.Fork-type frame,good hold-down property;
7.Hydraulic pump and vibration motors are of the products made by american manufacturer Danfoss;
Main Technical Parameters
Model | LTC212 | |
Operating mass | kg | 12000 |
Front axle load | kg | 6000 |
Rear axle load | kg | 6000 |
Static linear load | N/cm | 286 |
Form of frame | Fork-type | |
Water tank capacity | L | 2*600 |
Fuel tank capacity | L | 154 |
Hydraulic tank capacity | L | 65 |
Oriental vibration amplitude | mm | 0.4/0.8 |
Vibration frequency | HZ | 40/46 |
Centrifugal force | KN | 90*2/160*2 |
Travel speed | Km/h | 0-12 |
Turning radius | mm | 7000 |
Grade ability | % | 40 |
Drum diameter | mm | 1350 |
Drum width | mm | 2100 |
Drum rim thickness | mm | 20 |
Wheel base | mm | 3717 |
Overall dimension | mm | 5056*2250*3300 |
Ground clearance | mm | 324 |
Diesel model | Cummins6BT5.9 | |
Diesel power | kw | 110 |
Diesel speed | R/min | 2300 |
