LTC210 10 Tons Hydraulic Double Drum Vibrating Road Roller For Sale
Main Features
1.Full hydraulic two wheel drive and vibration;
2.Double frequency double vibration system;
3.Hydrostatic center articulated steering, patented crab mechanism;
4.Cab with air conditioner ,comfortable and spacious ,the flexible steering seat;
5.The driver’s cabin can be turned on one side as a whole, to facilitate maintenance;
6.Fork-type frame,good hold-down property;
7.Hydraulic pump and vibration motors are of the products made by american manufacturer Danforss ;
Main Technical Parameters
Model | LTC210 | |
Operating mass | kg | 10000 |
Front axle load | kg | 5000 |
Rear axle load | kg | 5000 |
Static linear load | N/cm | 238 |
Form of frame | Fork-type | |
Crabwise movement distance | mm | ±170 |
Water tank capacity | L | 2*400 |
Fuel tank capacity | L | 80 |
Hydraulic tank capacity | L | 65 |
Oriental vibration amplitude | mm | 0.67/0.34 |
Vibration frequency | HZ | 45/50 |
Centrifugal force | KN | 90*2/69*2 |
Travel speed | Km/h | 0-10 |
Turning radius | mm | 6000 |
Grade ability | % | 40 |
Drum diameter | mm | 1150 |
Drum width | mm | 1730 |
Drum rim thickness | mm | 20 |
Wheel base | mm | 3217 |
Overall dimension | mm | 4558*1840*2674 |
Ground clearance | mm | 258 |
Diesel model | Cummins4BT3.9 | |
Diesel power | kw | 75 |
Diesel speed | R/min | 2400 |
