Details
LTS214H 14 Tons Single Drum Vibrating Road Roller For Sale
Main Features
1.Power system:cummins turbocharged diesel engine,have high coefficient of power reserve,which comply with the operating condition above 4000 meters altitude;
2.Full hydraulic ,single wheel drive ,frequency and amplitude conversion ,articulated steering,with CVT,advanced technology;blocking the oil supply to brake the vehicle ,safe and reliable;
3.Streamline outline,circular windshield glass and curvy hood form a unique style;
4.Hydraulic pump and vibrating motors are the 90 series made by the american manufacturer Sauer;
Main Technical Parameters
Model | LTS214H | |
Operating mass | kg | 14000 |
Static linear | N/cm | 326 |
Vibration amplitude | HZ | 29/35 |
Centrifugal frequency | KN | 290/180 |
Oriental vibration amplitude | mm | 1.7/0.8 |
Max.travel speed | Km/h | 12 |
Grade ability | % | 30 |
Turning radius | mm | 7000 |
Overall dimension | mm | 5900*2280*3050 |
Drum width | mm | 2100 |
Wheelbase | mm | 3185 |
Min.ground clearance | mm | 400 |
Diesel power | kw | 110 |
Diesel model | Cummins6BT5.9 |
