LTS208H 8 Tons Hydraulic Single Drum Vibratory Road Roller
Main Features
1.Power system:cummins turbocharged diesel engine,have high coefficient of power reserve,which comply with the operating condition above 4000 meters altitude;
2.Full hydraulic ,single wheel drive ,frequency and amplitude conversion ,articulated steering,with CVT,advanced technology;blocking the oil supply to brake the vehicle ,safe and reliable;
3.Streamline outline,circular windshield glass and curvy hood form a unique style;
4.Hydraulic pump and vibrating motors are the 90 series made by the american manufacturer Danfoss;
Main Technical Parameters
Model | LTS208H | |
Operating mass | kg | 8000 |
Static linear | N/cm | 230 |
Vibration amplitude | HZ | 43 |
Centrifugal frequency | KN | 70 |
Oriental vibration amplitude | mm | 0.4 |
Max.travel speed | Km/h | 10 |
Grade ability | % | 25 |
Turning radius | mm | 6000 |
Overall dimension | mm | 5030*1880*2570 |
Drum width | mm | 1700 |
Wheelbase | mm | 2684 |
Min.ground clearance | mm | 280 |
Diesel power | kw | 75 |
Diesel model | Cummins4BT3.9 | |
Water tank capacity | L | 450 |
